SmallRig RF-10C 10W Creator Light - Lab Test
- Marvin Kuhn
- Lab report , Lights
- January 28, 2026
Table of Contents
SmallRig RF-10C – Technical Analysis
🔍 Important Specifications (Measurements at 5500K)
Classification:
The SmallRig RF-10C is not a classic RGB light, but rather a compact projection flashlight.
Color generation is achieved through fixed LEDs (White, Yellow, Blue, Red) – this is Pseudo-RGB, not a full RGBWW system.
| Parameter | Measured Value |
|---|---|
| Brightness White (Lux) | 397.76 |
| CRI (Ra) | 93.40 |
| R9 (Red Rendering) | 71 |
| TM-30 Rf / Rg | 92 / 100 |
| SSI | 73 |
| CCT Measured | 5955K |
| CCT Deviation (MK-1) | 13.89 |
| DUV (Green Cast) | +0.0032 |
✅ Strengths
Compact projection light with extensive accessories
→ Flashlight form factor with large selection of patterns, gobos and projection attachments.
→ Designed for textures, backgrounds and visual accents, not for classical illumination.
Controlled color cast
→ DUV +0.0032: minimal green cast, manageable in practice.
→ Sufficient for effect and projection lighting.
⚠️ Weaknesses
CRI value only average
→ CRI 93 is today no quality benchmark, but rather lower standard.
→ Combined with an R9 value of 71, only marginally suitable for skin tones.
Strong CCT deviations at different brightness levels
→ Color temperature changes significantly depending on dimming level.
→ Unsuitable for reproducible setups or consistent light moods.
No true RGB system
→ Colors are created from White, Yellow, Blue and Red.
→ Significantly limited color space compared to RGBWW or RGBCCT lights.
RGB colors significantly less bright
→ Color modes reach maximum around 2/3 of white light brightness.
→ Colored projections noticeably lose punch.
Very limited light output
→ Under 400 lux at white light (1 m):
Not usable as key, fill or rim light.
No real focus adjustment
→ Projection can only be influenced to a limited extent.
→ Patterns remain soft, edges not precisely controllable.
CCT accuracy only moderate
→ 5500K measures effectively ~5955K (MK-1: 13.89).
→ Unsuitable for mixed light or color-critical setups.
📉 Practical Application
Suitable for
→ Projection & effect lighting
→ Backgrounds, patterns & textures
→ Social media, reels & creative photography
→ Visual accents on set
Less suitable for
→ Interviews & corporate productions
→ Keylight, fill light or rim light use
→ Reproducible or color-critical workflows
📌 Conclusion
The SmallRig RF-10C is not a light for color or CCT stability, but rather a creative tool. Its strength lies clearly in the accessories and projection capabilities. Light quality is secondary and accordingly inconsistent – which is acceptable for its intended purpose, but sets clear limits for controlled lighting work.
👉 In short:
A specialized effect light for patterns and textures – not for precise or reproducible illumination.
